Stream - Industrial Multi-stage Pumps - SMS-I15

Description

SMS,SMS-F,SMS-I Pump is a kind of multifunctional products.It can be used to convey various medium from tap water to industrial liquid at different temperature and with different flow rate and pressure.

Application:

  • Irrigation
  • Water supply
  • Industrial pressure boost
  • Liquid transfer and delivery
  • Water treatment

Working Condition:

  • Thin, clean, non-flammable and non-explosive liquid containing no solid granules and fibers
  • Power range from 0.37 kW to 45 Kw
  • Flow range from 0.7 m³/h to 120 m³/h;
  • Head up to 309 m;
  • Temperature range from -20? to 180 ?

Features & Benefits

Pump

  • SMS,SMS-F,SMS-I are non-self priming vertical multistage centrifugal pumps.
  • The inlet and outlet are located at the pump bottom at the same plane - inline type.
  • All pumps are equipped with a maintenance-free mechanical seal of the cartridge type.

Motor

  • SMS,SMS-F,SMS-I are fitted with a totally enclosed, fan-cooled,2-pole,three-phase standard motor.
  • From 0.37kW to 2.2kW, single-phase motor is also available.

Motor Protection

  • Single-phase motor has a built-in thermal overload switch.
  • Three-phase motors must be connected to a motor protective circuit breaker according to local regulations.

Benefits

  • Nice appearance,light weight and less land area
  • High efficiency and energy saving
  • Nice appearance,light weight and Less land area
  • Small noise at running
  • Simple installation and maintenance
  • Safe and durable
