Stream - Industrial Submersible Pumps - SWSD

Application

  • Domestic/ Commercial /Industrial use
  • Handling waste water and sanitary waste water
  • Emptying cesspit and draining of sewage systems

Operating Conditions

  • Submersible depth:5m
  • Liquid temperature up to+40°C
  • Ambient temperature up to+40°C
  • Max working pressure: 6 bar
  • Passage of suspended solid up to 50mm

Motor

  • 2-pole induction motor
  • Insulation:Class B
  • Protection:IP X8
  • Single-phase with capacitor and thermal overload protection

Material

  • Pump body: Stainless steel(AISI304) orCast iron
  • Motor bracket: Stainless steel(AISI304)
  • Impeller: Stainless steel(AISI304)
  • Motor shaft:Stainless steel with 45#
  • Mechanical seal:Ceramic-Graphite
  • Copper winding
