Stream Irrigation Deep Well Pumps - 8CS95

Advantages

Utilization of to pclass materials. The CS series range of deep well submersible pumps are made of casting stainless steel. This provides maximum strength,durability,reliability, wear and tear resistance against sand or other impurities.

Superior design allows the pumps to be reliable, user friendly, maximum resistance to wear and tear,long lasting, easy of assembling and high hydraulic performance.

State of the art manufacturing process ensures the optimum quality. A specialized casting stainless steel process maximizes the toughness of the products. Finishing is done with CNC machines with a high degree tolerance capability of up to 0.05mm.The parts have an excellent alignment when assembled for optimum performance.

Applications

  • For water supply from wells or reservoirs.
  • For domestic use, for civil and industrial applications.
  • For garden use and irrigation.

Motor and Pump

  • Rewindable motor or Full obturated screen motor
  • Three-phase: 380v-415v/50Hz
  • Direct start (1 cable)
  • Star-deltastart (2 cable)
  • Equip with start control box or digital auto-control box
  • NEMA dimension standards
  • Curve tolerance according to ISO 2548

Operating conditions

  • Maximum fluid temperature up to ±50°C.
  • Maximum sand content: 0.25%.
  • Maximum immersion: 100m.
  • Minimum well diameter: 6″8″
