Stream - Irrigation Deep Well Pumps - 3SP1.8/2.5
Applications
- For water supply from wells or reservoirs.
- For domestic use, for civil and industrial applications.
- For garden use and irrigation.
Operating conditions
- Maximum fluid temperature up to +50°C.
- Maximum sand content: 0.25%.
- Maximum immersion: 80m.
- Minimum well diameter: 3”,3.5”,4”
Motor and Pump
- Rewindable motor or Full obturated screen motor
- Three-phase: 380v-415v/50Hz
- Single- phase: 220v-240v/50Hz
- Equip with start control box or digital auto-control box
- Curve tolerance according to ISO 9906
Options on request
- Special mechanical seal
- Other voltages or frequency 60 Hz
- Single phase motor with built-in capacitor
Advantages
- Italian technology is used for pump production.
- Slight motor heating, overload protection.
- High efficiency.
- Proper way of stainless steel treatment; pumps are environment friendly.
- Motor oil and seal lubricant oil is the oil for the food industry.
- Sand resistance.
- Assembling accuracy.
- Low energy consumption.
- Long lifetime.
