Stream - Domestic Self-priming Jet Pumps - SJETB

Applications and installation:

The SJETB series are injection typeclean water pumps, which are composed of a  centrifugal pump and a nozzle, have the advantages of beautiful design,self-priming in short time, reliable performance, high head and deep suction.They are suitable for pumping clean water and non-aggressive liquid. They are particularly suitable for domestic applications such as supply water from well,pool etc, the automatic distribution of water by surge tanks and pressure switch, gardening, andpressure boosting etc.

Pumps should be installed in a covered area, protected against the weather.

Operating limitations:

  • Max ambient temperature up to 40 ?
  • Max fluid temperature up to 40 ?
  • Max pressure up to 10 bar

Construction features

  • Pump Body: cast iron
  • Motor Housing: aluminum
  • Shaft:45# steel/stainless steel
  • Impeller:brass /stainless steel/PPO optional
  • Motor:closed, externally ventilated
  • Insulation Class: B/F
  • Protection Class: IP44/IP54
  • Duty:continuously rated
  • Mechanical Seal: ceramic steatite/metalized carbon
