Stream - Domestic Centrifugal Pumps - SCM

Applications and installation:

The SCM series pumps are with two back-to-back impellers centrifugal pumps, are developed for higher head valve than single impeller pumps and have extremely high outputs. They are suitable for pumping clean water and chemically non-aggressive liquid, reliable,economical and simple to use. They can be used for pressure boosting washing systems, cooling and fire-fighting units,Industrial water supplying,horticultural and agricultural irrigation applications, civil and domestic water transfer schemes, boiler, chiller and refrigeration systems.

Pumps should be installed in a covered area, protected against the weather.

Operating limitations:

  • Max ambient temperature up to 40 ?
  • Max fluid temperature up to 80 ?
  • Max pressure up to 10 bar

Construction features

  • Pump Body: cast iron
  • Motor Housing: aluminum/cast iron
  • Shaft:45# steel/stainless steel
  • Impeller:brass
  • Motor:closed, externally ventilated
  • Insulation Class: B/F
  • Protection Class: IP44/IP54
  • Duty:continuously rated
  • Mechanical Seal: ceramic steatite/metalized carbon
