Stream - Domestic Centrifugal Pumps - SHF

Applications and installation:

The SHF series pumps are specifically designed to achieve high delivery rates with low to medium heads for industrial and agricultural uses. Their volute impeller makes it able to pump water that is even fairly dirty. High delivery rates under continuous or heavy duty,making them advantageous for rain and gravity irrigation, for pumping water from lakes, river, well and for a wide variety of other applications, etc.

Pumps should be installed in a covered area, protected against the weather.

Operating limitations:

  • Max ambient temperature up to 40 °C
  • Max fluid temperature up to 80 °C
  • Max pressure up to 10 bar

Construction features

  • Pump Body: cast iron
  • Motor Housing: aluminum
  • Shaft:45# steel/stainless steel
  • Impeller:brass
  • Motor:closed, externally ventilated
  • InsulationClass: B/F
  • ProtectionClass: IP44/IP54
  • Duty:continuously rated
  • Mechanical Seal: ceramic steatite/metalized carbon
